Hand Drum Pump, Stainless Steel, 3/4In OD

Home / Hand Drum Pump, Stainless Steel, 3/4In OD

Hand Drum Pump, Stainless Steel, 3/4In OD

SKU
Brand Action Pump
Categories Pumps
Description Hand Operated Drum Pump, Max. Outlet Pressure 5 psi, Spout Connection Size 49/64 in, Self-Priming Yes, Metered No, Includes Discharge Hose No, Piston Material PTFE, Features All Stainless and PTFE Construction, Three Piece Intake Tube, Seal Material PTFE, For Use With For Viscous Liquids, Detergents, Most Acids, Oils, Waxes, Alkalis, Water, and Soaps, Adapter Connection Type MNPT, For Container Type Drum, Includes Bung Adapter Yes, Includes Nozzle No, Includes Spout Yes, Runs Dry Yes
graingerSKU: 6PFL4, mscSKU: , zoro_no: G6807972, mongo_id: 65bbe9b522d7a989a9971aaa

Web Price

$338.74 / each

Qty

Product Details

Action Type Lever

Adapter Connection Type MNPT

Adapter Dia. 2

Adapter Material Polypropylene

Adapter Type Bung

Agency Compliance ISO 22241-3

Application For Viscous Liquids, Detergents, Most Acids, Oils, Waxes, Alkalis, Water, and Soaps

Bung Connection Dia. 2 in

Compatible Chemicals Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Acetone, Additional Chemicals (If needed by supplier), Ammonia (Liquids), Ammonium Hydroxide, Anhydrous Ammonia, Antifreeze (Coolant), Automatic Transmission Fluid, Biodiesel, Brake Fluid, Calcium Chloride, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Citric Acid 50%, Cyclohexane, DEF, Deionized Water, Diesel Fuel, E85, Ethyl (Ethanol), Ethyl Acetate, Ethylene Glycol, Fertilizers, Formaldehyde, Formaldehyde 40%, Formic Acid, Fresh Water, Fungicides, Gasoline, Glycerin, Heptane, Herbicides, Hexane, Hydraulic Oils (Petroleum), Hydraulic Oils (Synthetic), Hydrazine, Isopropyl (Isopropanol), Kerosene, Lacquer Thinners, Lithium Grease, Methyl (Methanol), Methyl Chloride, Methyl Ethyl Ketone (MEK), Motor Oil, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Paint, Paint Thinner, Pesticides, Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Sodium Hypochlorite/Bleach (to 20%), Stoddard Solvent (Mineral Spirits), Toluene, Trichlorethylene (50%), Turpentine, Windshield Washer Fluid, Xylene

Country of Origin (subject to change) Taiwan, Province of China

Diesel Exhaust Fluid Compatible Yes

Discharge Tube Length 6

Discharge Tube Outlet ID 3/4 in

Discharge Tube Outlet OD 7/8 in

Discharge Tube Outlet OD Size 3/4

Discharge Tubing Material 304 Stainless Steel

Features All Stainless and PTFE Construction, Three Piece Intake Tube

Food Grade No

For Container Size 30 gal, 55 gal

For Container Type Drum

For Media Type Acetic Acid, Ammonium Hydroxide, Antifreeze, Biodiesel, Bleach, Calcium Chloride, Chromic Acid, Citric Acid, Cyclohexane, Diesel Fuel, Ethanol, Ethyl Acetate, Ethylene Glycol, Formaldehyde, Formic Acid, Gasoline, Glycerin, Heptane, Hexane, Hydraulic Oil, Hydrazine, Isopropanol, Kerosene, Ketones, Lacquer Thinners, Methanol, Methyl Chloride, Motor Oil, Nitric Acid, Sodium Bicarbonate, Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide, Stoddard Solvent, Toluene, Trichlorethylene, Water, Xylene

For Use With For Viscous Liquids, Detergents, Most Acids, Oils, Waxes, Alkalis, Water, and Soaps

Gasket Material PTFE

Gear Lube NT

GPM 5

Grease NT

Height Above Container 19 3/4 in

Housing Material 304 Stainless Steel

Housing Material - Pumps 304 Stainless Steel

Includes 2 in Bung Adapter

Includes Bung Adapter Yes

Includes Discharge Hose No

Includes Nozzle No

Includes Spout Yes

Includes Suction Tube Yes

Inlet Size 1

Manufacturers Warranty Length 1 yr.

Max. Flow Rate 12 oz per stroke

Max. Fluid Temp. 140 Degrees F

Max. GPM for Water 9

Max. Head 3 ft.

Max. Head - Pumps 3 ft

Max. Head Pressure 3 psi

Max. Liquid Temp. 140 Degrees F

Max. Outlet Pressure 5 psi

Max. Pressure 20 psi

Max. Temp. 140 Degrees F

Max. Viscosity 650 cps

Metered No

Min. Operating Temp. 35 Degrees F

Not Recommended Chemicals Hydrochloric/Muriatic Acid (100%), Hydrofluoric Acid (20%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Phosphoric Acid (40% Solution), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%)

Ounces per Stroke 12 oz.

Outlet Size 3/4

Overall Length 54

Package Quantity 1

pH Range 5 to 9

Piston Material PTFE

Power Source Hand Operated

Pump Connection ID 1 in

Runs Dry Yes

Seal Material PTFE

Self-Priming Yes

Spout Connection Size 49/64 in
