Home / 1" x 1-1/4" Violet Wire Marking Sleeves, PS-750-2-VT-2

1" x 1-1/4" Violet Wire Marking Sleeves, PS-750-2-VT-2

SKU
Brand Brady
Categories
Description Precut Label Roll, For Print Method Thermal-Transfer, Resistance Properties Chemical-Resistant, Cold-Resistant, Corrosion-Resistant, Fade-Resistant, Flame-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant, Material Series B-342, Double-Sided Printable No, Label Material Polyolefin, Maximum Wire Diameter 0.22 in, Minimum Wire Diameter 0.09 in, Maximum Wire Gauge 8 AWG, Minimum Wire Gauge 16 AWG, Compatible Grainger Part Number 30DA02, 30DA42, 30DA43
graingerSKU: 31EC90, mscSKU: , zoro_no: G6447165, mongo_id: 65bbe92f22d7a989a993e353

Web Price

$476.24 / each

Qty

Product Details

Adhesive Non-Adhesive

Adhesive Material Not Applicable

Application Wire and Cable Labeling

Color Violet ( Matte )

Compatible Mfr Part Number IP-R6600, IP-R6700-WT, R6600, R6700-WT

Core Diameter 3 in

Country of Origin (subject to change) United States

Double-Sided Printable No

For Print Method Thermal-Transfer

For Use With Thermal Transfer Printers

For Wire Diameter 0.094 in to 0.215 in

For Wire Gauge 8 AWG to 16 AWG

Height 1 1/4 in

Label Attachment Style Heat Shrink Sleeve

Label Color Violet

Label Color & Finish - Heat-Shrink Cable & Wire Labels Violet ( Matte )

Label Finish Matte

Label Height 1 in

Label Material Polyolefin

Label Media Format Precut Roll

Label Size (HxW) - Heat-Shrink Cable & Wire Labels 3/4 in x 1 in

Label Width 3/4 in

Labels per Roll 500

Labels per Row 2

Legend None

Material Brady B-342 Heat Shrink Polyolefin Double-Sided Print

Material Properties Heat-Shrinkable

Material Series B-342

Max. Lines of Print Varies

Max. Wire Size 0.7 in

Maximum Service Temperature 275 Degrees F

Maximum Wire Diameter 0.22 in

Maximum Wire Gauge 8 AWG

Min. Wire Size 0.25 in

Minimum Service Temperature -67 Degrees F

Minimum Wire Diameter 0.09 in

Minimum Wire Gauge 16 AWG

Package Quantity 1

Printer Series Compatibility BBP72, i5100, i7100, IP Series, THT

Product Type Wire Marking Sleeve

Recommended Ribbon IP-R6600, IP-R6700-WT, R6600, R6700-WT

Resistance Properties Chemical-Resistant, Cold-Resistant, Corrosion-Resistant, Fade-Resistant, Flame-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant

Shrink Ratio 3:1

Standards ASTM D 2671, ASTM E 162, ASTM E 662, ASTM G 155, MIL-STD-202, SAE AS23053/5, SAE-AMS-DTL-23053, SAE-AS-81531, UL Recognized

Temp. Range -67 Degrees to 275 Degrees F

Width 1 in
