1" x 21/64" White Wire Marking Sleeves, B33-187-2-342-2

SKU
Brand Brady
Categories
Description Precut Label Roll, For Print Method Thermal-Transfer, Resistance Properties Chemical-Resistant, Cold-Resistant, Corrosion-Resistant, Fade-Resistant, Flame-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant, Material Series B-342, Double-Sided Printable No, Label Material Polyolefin, Maximum Wire Diameter 1.43 in, Minimum Wire Diameter 0.72 in, Maximum Wire Gauge 10 AWG, Minimum Wire Gauge 20 AWG, Compatible Grainger Part Number 6XGZ2
graingerSKU: 45KK17, mscSKU: , zoro_no: G1583727, mongo_id: 65bbe7f59a749db8227678ba

Web Price

$792.49 / each

Qty

Product Details

Adhesive Non-Adhesive

Adhesive Material Not Applicable

Application Electrical Labeling, Wire and Cable Labeling

Color White ( Matte )

Compatible Mfr Part Number B30-R4300

Country of Origin (subject to change) Mexico

Double-Sided Printable No

For Print Method Thermal-Transfer

For Use With Printer Mfr. No. BBP33-C and Ribbon Series R2000, R4300, R4502S, R5000, R6600, R6700

For Wire Diameter 0.72 in to 1.43 in

For Wire Gauge 10 AWG to 20 AWG

Height 21/64 in

Indoor/Outdoor Usage Outdoor

Label Attachment Style Heat Shrink Sleeve

Label Color White

Label Color & Finish - Heat-Shrink Cable & Wire Labels White ( Matte )

Label Finish Matte

Label Height 1 in

Label Material Polyolefin

Label Media Format Precut Roll

Label Size (HxW) - Heat-Shrink Cable & Wire Labels 3/16 in x 1 in

Label Width 3/16 in

Labels per Roll 1,500

Labels per Row 2

Legend Blank

Material Brady B-342 PermaSleeve(R) Heat-Shrink Polyolefin

Material Properties Heat-Shrinkable

Material Series B-342

Max. Wire Size 0.15 in

Maximum Service Temperature 275 Degrees F

Maximum Wire Diameter 1.43 in

Maximum Wire Gauge 10 AWG

Metal Detectable No

Min. Wire Size 0.062 in

Minimum Service Temperature -67 Degrees F

Minimum Wire Diameter 0.72 in

Minimum Wire Gauge 20 AWG

Package Quantity 1

Printer Series Compatibility BBP33, i3300

Product Type Wire Marking Sleeve

Recommended Ribbon B30-R4300

Resistance Properties Chemical-Resistant, Cold-Resistant, Corrosion-Resistant, Fade-Resistant, Flame-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant

Shrink Ratio 3:1

Standards MIL-STD-202, RoHS Compliant, SAE-AMS-DTL-23053/5C (Class 1), SAE-AS-81531, UL Recognized

Temp. Range -67 Degrees to 275 Degrees F

Width 1 in
