1" x 27/32" Violet Wire Marking Sleeves, 3PS-500-2-VT-2

SKU
Brand Brady
Categories
Description Precut Label Roll, For Print Method Thermal-Transfer, Resistance Properties Chemical-Resistant, Cold-Resistant, Corrosion-Resistant, Fade-Resistant, Flame-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant, Material Series B-342, Double-Sided Printable Yes, Label Material Polyolefin, Maximum Wire Diameter 0.15 in, Minimum Wire Diameter 0.06 in, Maximum Wire Gauge 10 AWG, Minimum Wire Gauge 20 AWG, Compatible Grainger Part Number 30DA02, 30DA42, 30DA43
graingerSKU: null, mscSKU: null, zoro_no: G6488772, mongo_id: 65bbe6cd3aaddbd5a9054925

Web Price

$869.99 / each

Qty

Product Details

Adhesive Non-Adhesive

Adhesive Material Not Applicable

Application Wire and Cable Labeling

Color Violet ( Matte )

Compatible Mfr Part Number IP-R6600, IP-R6700-WT, R6600, R6700-WT

Core Diameter 3 in

Country of Origin (subject to change) United States

Double-Sided Printable Yes

For Print Method Thermal-Transfer

For Use With Thermal Transfer Printers

For Wire Diameter 0.062 in to 0.15 in

For Wire Gauge 10 AWG to 20 AWG

Height 27/32 in

Label Attachment Style Heat Shrink Sleeve

Label Color Violet

Label Color & Finish - Heat-Shrink Cable & Wire Labels Violet ( Matte )

Label Finish Matte

Label Height 1 in

Label Material Polyolefin

Label Media Format Precut Roll

Label Size (HxW) - Heat-Shrink Cable & Wire Labels 1/2 in x 1 in

Label Width 1/2 in

Labels per Roll 1,000

Labels per Row 2

Legend None

Material Brady B-342 Heat Shrink Polyolefin Double-Sided Print

Material Properties Heat-Shrinkable

Material Series B-342

Max. Lines of Print Varies

Max. Wire Size 0.45 in

Maximum Service Temperature 275 Degrees F

Maximum Wire Diameter 0.15 in

Maximum Wire Gauge 10 AWG

Min. Wire Size 0.187 in

Minimum Service Temperature -67 Degrees F

Minimum Wire Diameter 0.06 in

Minimum Wire Gauge 20 AWG

Package Quantity 1

Printer Series Compatibility BBP72, i5100, i7100, IP Series, THT

Product Type Wire Marking Sleeve

Recommended Ribbon IP-R6600, IP-R6700-WT, R6600, R6700-WT

Resistance Properties Chemical-Resistant, Cold-Resistant, Corrosion-Resistant, Fade-Resistant, Flame-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant

Shrink Ratio 3:1

Standards ASTM D 2671, ASTM E 162, ASTM E 662, ASTM G 155, MIL-STD-202, SAE-AMS-DTL-23053, SAE-AS-81531, UL Recognized

Temp. Range -67 Degrees to 275 Degrees F

Width 1 in
