Home / 3-Phase General Purpose Motor, 1 HP, 182/4 Frame, 208-230/460V AC Voltage, 1,170 Nameplate RPM
3-Phase General Purpose Motor, 1 HP, 182/4 Frame, 208-230/460V AC Voltage, 1,170 Nameplate RPM
3-Phase General Purpose Motor, 1 HP, 182/4 Frame, 208-230/460V AC Voltage, 1,170 Nameplate RPM
3-Phase General Purpose Motor, 1 HP, 182/4 Frame, 208-230/460V AC Voltage, 1,170 Nameplate RPM
3-Phase General Purpose Motor, 1 HP, 182/4 Frame, 208-230/460V AC Voltage, 1,170 Nameplate RPM
3-Phase General Purpose Motor, 1 HP, 182/4 Frame, 208-230/460V AC Voltage, 1,170 Nameplate RPM

3-Phase General Purpose Motor, 1 HP, 182/4 Frame, 208-230/460V AC Voltage, 1,170 Nameplate RPM

  • Dayton
  • General Purpose Motor, Three Phase, Motor Design 3-Phase, 1 hp HP, Nameplate RPM 1,170, No. of Speeds 1, Voltage 208-230/460V AC, Full Load Amps 3.2/1.6 A, 182/4 Frame, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 104 Degrees F, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class F, Motor Enclosure Design Totally Enclosed Fan-Cooled, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base, Motor Mounting Position Horizontal, Inverter Rated Yes

    graingerSKU: , mscSKU: , zoro_no: G1860708, mongo_id: 65bbe9a422d7a989a996ac45

Web Price
$739.99 / each
Qty

Product Details

No
CC029A
Mexico
Continuous
Continuous
2,15,53
182/4
Rolled steel
3.2/1.6 A
NEMA Premium Rated
Product Contributes To Reducing Energy Consumption
1
60 Hz
Conduit Box
F
Yes
13 9/16 in
1 yr
104 Degrees F
General Application
Ball
3-Phase
Premium Efficient
Totally Enclosed Fan-Cooled
Rolled Steel
Horizontal
Rigid Base
1.15
Keyed
CW/CCW
None
1,170
1
82.5 %
15 7/8 in
1
Three
1101-1200
1,101-1,200
7/8 in
2 1/4 in
CE, CSA, UL
208-230/460V AC
200-230/440V AC, 200-230/460V AC, 208-230/460V AC, 460V AC
