Home / 3-Phase General Purpose Motor, 1/2 HP, 56 Frame, 230/460V AC Voltage, 1,140 Nameplate RPM
3-Phase General Purpose Motor, 1/2 HP, 56 Frame, 230/460V AC Voltage, 1,140 Nameplate RPM
3-Phase General Purpose Motor, 1/2 HP, 56 Frame, 230/460V AC Voltage, 1,140 Nameplate RPM
3-Phase General Purpose Motor, 1/2 HP, 56 Frame, 230/460V AC Voltage, 1,140 Nameplate RPM
3-Phase General Purpose Motor, 1/2 HP, 56 Frame, 230/460V AC Voltage, 1,140 Nameplate RPM
3-Phase General Purpose Motor, 1/2 HP, 56 Frame, 230/460V AC Voltage, 1,140 Nameplate RPM

3-Phase General Purpose Motor, 1/2 HP, 56 Frame, 230/460V AC Voltage, 1,140 Nameplate RPM

  • Dayton
  • General Purpose Motor, Three Phase, Motor Design 3-Phase, 1/2 hp HP, Nameplate RPM 1,140, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 2.8/1.4 A, 56 Frame, Hz 60/50 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 104 Degrees F, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Dripproof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base, Motor Mounting Position Horizontal, Inverter Rated Yes, Motor Shaft Design Keyed

    graingerSKU: 31TT11, mscSKU: , zoro_no: G8571263, mongo_id: 65bbe6cf3aaddbd5a9055f6f

Web Price
$847.49 / each

Product Details

No
Mexico
Continuous
Continuous
5,10
56
Rolled steel
2.8/1.4 A
Energy Aware
Product Contributes To Reducing Energy Consumption
1/2 hp
60/50 Hz
Shaft Slinger
B
Yes
9 3/4 in
1 yr
104 Degrees F
General Application
Ball
3-Phase
Premium Efficient
Open Dripproof
Rolled Steel
Horizontal
Rigid Base
1.25
Keyed
CW/CCW
None
1,140
1
75.3 %
11 11/16 in
1
Three
Not eligible for promotion
1101-1200
1,101-1,200
5/8 in
1 7/8 in
UL Recognized for US and Canada (E47479)
230/460V AC
200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
