AC Gearmotor, 1,017.0 in-lb Max. Torque, 18 RPM Nameplate RPM, 115V AC Voltage, 1 Phase
AC Gearmotor, 1,017.0 in-lb Max. Torque, 18 RPM Nameplate RPM, 115V AC Voltage, 1 Phase
AC Gearmotor, 1,017.0 in-lb Max. Torque, 18 RPM Nameplate RPM, 115V AC Voltage, 1 Phase

AC Gearmotor, 1,017.0 in-lb Max. Torque, 18 RPM Nameplate RPM, 115V AC Voltage, 1 Phase

  • Dayton
  • AC Gearmotor, Number of Output Shafts 1, Motor Type Split-Phase, Motor Enclosure Totally Enclosed Fan-Cooled, Nameplate Speed 18 RPM, Maximum Torque 1,017 in-lb, Overhung Load Capacity 325 ft-lb, Rotation CW/CCW, Output Shaft Height 3 in, Mounting Orientation Any Angle, Operating Voltage 115V AC, Inverter Rated Yes, Gear Ratio 95:1, Brake Type None, Shaft Orientation Parallel, AGMA Gear Class Class 9

    graingerSKU: 6Z402, mscSKU: , zoro_no: G0813093, mongo_id: 65bbe86522d7a989a98f09e8

Web Price
$1,347.49 / each
Qty

Product Details

Class 9
Ball on Motor, Heavy Duty Ball, Needle Roller and Thrust Balls on Case
Ball on Motor, Heavy Duty Ball, Needle Roller and Thrust Balls on Case
Adaptable to 4Z447
None
United States
TEFC
60 Hz
5.5
5.5 A
Die Cast Aluminum
Hardened Steel
95:1
Helical (1st Stage), Spur (Subsequent Stages)
None
Totally Enclosed Fan-Cooled
All Angle
1
CW/CCW
Parallel
Single
AC Gearmotor
115V AC
1st Stage Helical, AGMA Class 9, Hardened Steel, Subsequent Stages Spur
Die Cast Aluminum
Die Cast Aluminum
60 Hz
0.33 hp
1/3 hp
Yes
95:1
0 in
Rounded
3/16 mm
12.31 in
Permanent Heavy Duty Gear Oil
40 Degrees C
1,017 in-lb
104 Degrees F
1,017 in-lb
Totally Enclosed Fan-Cooled
Split-Phase
2.5 in
7.13 in
Any Position
All Position
Any Angle
18 RPM
18 RPM
1
115V AC
3/4 in
3 in
1 1/2 in
6.63 in
8.13 in
325 lb
325 ft-lb
1
Single
CW/CCW
16 to 30
Lip Type on Input and Output Shaft
Lip Type on Input and Output Shaft
3/4 in
1.5 in_x000D_
Parallel
CSA Certified, UL Recognized
None
115
