Home / AC Gearmotor, 1,100.0 in-lb Max. Torque, 12 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 1,100.0 in-lb Max. Torque, 12 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 1,100.0 in-lb Max. Torque, 12 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 1,100.0 in-lb Max. Torque, 12 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase

AC Gearmotor, 1,100.0 in-lb Max. Torque, 12 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase

  • Dayton
  • AC Gearmotor, Number of Output Shafts 2, Motor Type Permanent Split Capacitor, Motor Enclosure Totally Enclosed Fan-Cooled, Nameplate Speed 12 RPM, Maximum Torque 1,100 in-lb, Overhung Load Capacity 550 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Operating Voltage 115/230V AC, Inverter Rated Yes, Gear Ratio 138:1, Brake Type None, Shaft Orientation Inline, AGMA Gear Class Class 9, Application Washdown

    graingerSKU: 1L509, mscSKU: , zoro_no: G2676091, mongo_id: 65bbe92322d7a989a9938239

Web Price
$1,189.99 / each
Qty

Product Details

Class 9
Washdown
Ball on Motor, Heavy Duty Ball and Needle Roller on Case
Ball on Motor, Heavy Duty Ball and Needle Roller on Case
Adaptable to 5X400
None
Yes
United States
2.35/1-1/4 in
TEFC
50 Hz, 60 Hz
2.4/1.2
2.4/1.2 A
Die Cast Aluminum
Hardened Steel
138:1
Helical (1st Stage), Spur (Subsequent Stages)
None
Totally Enclosed Fan-Cooled
All Angle
1
CW/CCW
Parallel
Double
AC Gearmotor
115/230V AC
1st Stage Helical, AGMA Class 9, Hardened Steel, Subsequent Stages Spur
Die Cast Aluminum
Die Cast Aluminum
60/50 Hz
0.25 hp
1/4 hp
Yes
138:1
9.75 in
Permanent Heavy Duty Gear Oil
40 Degrees C
1,100 in-lb
104 Degrees F
1,100 in-lb
Totally Enclosed Fan-Cooled
Permanent Split Capacitor
Any Position
All Position
Any Angle
12 RPM
12 RPM
2
115/230V AC
3/4 in
2 in
550 lb
550 ft-lb
1
Single
CW/CCW
10 RPM
0 to 15
Lip Type on Input and Output Shaft
Lip Type on Input and Output Shaft
Dual Output
3/4 in
2_x000D_ in
Inline
CE, CSA, UL Recognized
None
115/230
