Home / AC Gearmotor, 100.0 in-lb Max. Torque, 17 RPM Nameplate RPM, 230V AC Voltage, 1 Phase
AC Gearmotor, 100.0 in-lb Max. Torque, 17 RPM Nameplate RPM, 230V AC Voltage, 1 Phase
AC Gearmotor, 100.0 in-lb Max. Torque, 17 RPM Nameplate RPM, 230V AC Voltage, 1 Phase

AC Gearmotor, 100.0 in-lb Max. Torque, 17 RPM Nameplate RPM, 230V AC Voltage, 1 Phase

  • Dayton
  • AC Gearmotor, Number of Output Shafts 1, Motor Type Permanent Split Capacitor, Motor Enclosure Open Air-Over, Nameplate Speed 17 RPM, Maximum Torque 100 in-lb, Overhung Load Capacity 90 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Operating Voltage 230V AC, Inverter Rated Yes, Gear Ratio 96:1, Brake Type None, Shaft Orientation Parallel, Includes Capacitor Yes, Application Washdown

    graingerSKU: null, mscSKU: null, zoro_no: G2215771, mongo_id: 65bbe5f43aaddbd5a9ff898c

Web Price
$463.74 / each
Qty

Product Details

Washdown
Ball on Motor, Heavy Duty Needle on Case
Ball on Motor, Heavy Duty Needle on Case
Adaptable to 5X400
None
Yes
United States
9.23 in
4.92
2.1
Open
50 Hz, 60 Hz
0.3
0.3 A
Steel or Heat Treated Powdered Metal
96:1
Helical (1st Stage), Spur
None
Open
All Angle
1
CW/CCW
Parallel
Single
AC Gearmotor
230V AC
1st Stage Steel, Helical, Subsequent Stages Steel or Heat Treated Powdered Metal Spur
Rolled Steel
60/50 Hz
Yes
0.05 hp
1/20 hp
Yes
96:1
8.25 in
Permanent Heavy Duty Gear Oil
40 Degrees C
100 in-lb
104 Degrees F
100 in-lb
Open Air-Over
Permanent Split Capacitor
Any Position
All Position
Any Angle
17 RPM
17 RPM
1
230V AC
1/2 in
1 in
5.38 in
3.63 in
90 lb
90 ft-lb
1
Single
CW/CCW
16 to 30
Spring Loaded Lip Type on Input and Output Shaft
Spring Loaded Lip Type on Input and Output Shaft
1/2 in
1
Parallel
C-UL Recognized, CE Certified, UL Recognized
None
230
