Home / AC Gearmotor, 330.0 in-lb Max. Torque, 40 RPM Nameplate RPM, 115V AC Voltage, 1 Phase
AC Gearmotor, 330.0 in-lb Max. Torque, 40 RPM Nameplate RPM, 115V AC Voltage, 1 Phase
AC Gearmotor, 330.0 in-lb Max. Torque, 40 RPM Nameplate RPM, 115V AC Voltage, 1 Phase

AC Gearmotor, 330.0 in-lb Max. Torque, 40 RPM Nameplate RPM, 115V AC Voltage, 1 Phase

  • Dayton
  • AC Gearmotor, Number of Output Shafts 1, Motor Type Split-Phase, Motor Enclosure Open Dripproof, Nameplate Speed 40 RPM, Maximum Torque 330 in-lb, Overhung Load Capacity 190 ft-lb, Rotation CW/CCW, Output Shaft Height 3 in, Mounting Orientation Any Angle, Operating Voltage 115V AC, Inverter Rated Yes, Gear Ratio 43:1, Brake Type None, Shaft Orientation Parallel, Motor Insulation Class B

    graingerSKU: 1LPP3, mscSKU: , zoro_no: G0798987, mongo_id: 65bbe8d822d7a989a991b814

Web Price
$967.49 / each
Qty

Product Details

Ball on Motor, Porous Bronze Sleeve on Case
Ball on Motor, Porous Bronze Sleeve on Case
None
United States
ODP
Unpainted
60 Hz
4.1
4.1 A
Die Cast Zinc
Phenolic, Steel
43:1
None
Open Dripproof
All Angle
1
CW/CCW
Parallel
Single
AC Gearmotor
115V AC
Phenolic/Steel
Die Cast Zinc
Die Cast Zinc
Unpainted
60 Hz
0.25 hp
1/4 hp
b
Yes
43:1
5/8 in
#605 Woodruff Key
#605 Woodruff Key
Woodruff
3/16 in
9.63 in
Grease Filled
40 Degrees C
330 in-lb
104 Degrees F
330 in-lb
Open Dripproof
B
Split-Phase
2.38 in
7.13 in
Any Position
All Position
Any Angle
40 RPM
40 RPM
1
115V AC
3/4 in
3 in
1 1/2 in
6 in
8.13 in
190 lb
190 ft-lb
1
Single
No
CW/CCW
31 to 50
Lip Type on Input and Output Shaft
Lip Type on Input and Output Shaft
Single Output
3/4 in
1.5 in_x000D_
Parallel
C-UL Recognized, UL Recognized
None
115
