Home / AC Gearmotor, 340.0 in-lb Max. Torque, 14 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 340.0 in-lb Max. Torque, 14 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 340.0 in-lb Max. Torque, 14 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 340.0 in-lb Max. Torque, 14 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase

AC Gearmotor, 340.0 in-lb Max. Torque, 14 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase

  • Dayton
  • AC Gearmotor, Number of Output Shafts 1, Motor Type Permanent Split Capacitor, Motor Enclosure Totally Enclosed Fan-Cooled, Nameplate Speed 14 RPM, Maximum Torque 340 in-lb, Overhung Load Capacity 300 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Operating Voltage 115/230V AC, Inverter Rated Yes, Gear Ratio 114:1, Brake Type None, Shaft Orientation Parallel, Motor Insulation Class B

    graingerSKU: 1LPX3, mscSKU: , zoro_no: G0826122, mongo_id: 65bbe65b3aaddbd5a9023a66

Web Price
$777.49 / each
Qty

Product Details

Ball and Needle on Case, Ball on Motor
Ball and Needle on Case, Ball on Motor
5X400
None
Yes
United States
TEFC
Unpainted
50 Hz, 60 Hz
1.2/0.63
1.2/0.63 A
Die Cast Aluminum
Hardened Steel
114:1
Helical (1st Stage), Spur (Subsequent Stages)
None
Totally Enclosed Fan-Cooled
All Angle
1
CW/CCW
Parallel
Single
AC Gearmotor
115/230V AC
1st Stage Helical, Hardened Steel, Subsequent Stages Spur
Aluminum Die Cast
Aluminum Die Cast Alloy
Unpainted
60/50 Hz
0.083 hp
1/12 hp
b
Yes
114:1
1 in
3/16 in
9.5 in
Grease Filled
40 Degrees C
340 in-lb
104 Degrees F
340 in-lb
Totally Enclosed Fan-Cooled
B
Permanent Split Capacitor
3.63 in
Any Position
All Position
Any Angle
14 RPM
14 RPM
1
1
115/230V AC
3/4 in
1 3/8 in
4.88 in
5.63 in
300 lb
300 ft-lb
1
Single
No
CW/CCW
13
0 to 15
Lip Type on Input and Output Shaft
Lip Type on Input and Output Shaft
Single Output
3/4 in
1.375 in
Parallel
C-UL Recognized, UL Recognized
None
115/230
