Blower
Web Price
$7,859.99
/ each
Product Details
I
Heating, Air Conditioning, Ventilating and Similar Systems where Low to Medium Pressures are Encountered
Unassembled
Ball
820/975/1115/1225
United States
52 7/16 in
36 1/4 in
16 1/2 in
32 1/4 in
23 3/8 in
16 1/2 in
29 1/2 in
24 5/8 in
20 1/2 in
28 1/8 in
23 5/8 in
36 in
13 3/4 in
32 1/4 in
26 in
28 3/4 in
51 7/8 in
27 in
33 3/4 in
1/2 in
Bottom Angular Up, Down Blast, Top Angular Down, Top Angular Up, Top Horizontal, Up Blast
Belt Drive
Ground Wire
Dynamically Balanced Wheels Sizes 10-1/2 in to 24-1/2 in Feature Flat Blade Wheel, Larger Sizes Have Fixed Sheave Drive, Motor Cannot Be Overloaded at any Given Rpm and Horsepower Regardless of Static Pressure Applied to the System, Ratings Do Not Include the Effects of Duct End Correction, Sizes 10-1/2 in to 20 in Have Variable-Pitch Sheaves, Sizes 27 in to 36-1/2 in Have Airfoil Wheel Both Wheel Styles Provide Full Class 1 Performance Range, Values Shown for Blowers are for (Inlet Lwi) Sound Levels For: Installation Type B: Free Inlet, Ducted Outlet
6,869 cfm to 16,321 cfm
58 3/8 in
Gray
Gray Baked Polyester Epoxy
Steel
Gray Polyester Epoxy
Epoxy Coated Steel Weather Proof Drive Cover
No
32 1/4 in
32 1/4 in
1 yr Limited
104 Degrees F
250 Degrees F
16,321 cfm
104 Degrees F
1,225 RPM
250 Degrees F
10 hp
5 in wc
6,869 cfm
820 RPM
3 hp
3 to 10
Motor Mount
6
1
Not Applicable
32 1/4 in
32 1/4 in
Rectangular
32 1/4 in x 23 3/8 in
23 3/8 in
23 3/8 in
52 3/8 in
58 3/8 in
51 3/4 in
1
CW
1 11/16 in
1 5/8 in
AMCA Certified, NEC, OSHA
Yes
Backward Incline Belt Drive less Drive Package
30 in
30 in
30 in Dia. x 10 3/4 in W
Steel
Backward-Inclined
10 3/4 in
10 3/4 in
Steel Wheel and Steel Housing
51 3/4 in
