Brake, Magnetic Disc, Torque 10 Ft-Lb

  • Dayton
  • Washdown Brake, Clutch/Brake Type Double C-Face Magnetic Disc Brake, Coil Voltage 115/208-230V AC, Operating Voltage 115/208-230V AC @ 60 Hz, 95/174-190V AC @ 50 Hz, Enclosure Type Totally Enclosed, Static Torque 10 ft-lb, Motor Frame Designation 56C/140TC NEMA/IEC, Horsepower @ RPM 3 hp @ 1725 RPM, 5 hp @ 3450 RPM, Shaft Diameter 5/8 in, Maximum Speed 3,450 RPM, Mounting Location NEMA C-Face Flanges on Motors and Gear Reducers

    graingerSKU: 2LYU7, mscSKU: , zoro_no: G0464371, mongo_id: 65bbe89622d7a989a9903cf1

Web Price
$1,781.24 / each
Qty

Product Details

BISSC Certified, Complies with 3A Dairy Standards, Complies with NEMA Definition MG1-1.26.5, CSA, USDA Approved
40 Degrees C
0.34/0.17
Stops and Holds Rotating Loads on Bakery and Food Processing Equipment
Yes
Horizontal
Double C-Face Magnetic Disc Brake
115/208-230V AC
115/208-230V AC Or 95/174-190V AC
Yes
NEMA C-Face BISSC & Stainless Steel Motors and Gear Reducers to a Geared Brake Motor
United States
6 7/8 in
Continuous
BISSC Watertight/ Dust Proof
Totally Enclosed
Easily Installed
White Epoxy Paint
Washdown
Single and Three Phase BISSC and Stainless Steel C-Face Motors Used in Food Washdown Applications
50 Hz, 60 Hz
Spring Set Brake With Automatic Reset Release
0.34/0.17 A
3 hp @ 1725 RPM, 5 hp @ 3450 RPM
White Epoxy Paint
60/50
Hardware
2.43/1.22
2.43/1.22 A
15 in
4.875 in
Manual
Manual Release
3 hp
5 hp
3,450 RPM
40 Degrees C
3,450 RPM
56C/140TC NEMA/IEC
Horizontal
NEMA C-Face Flanges On Motors And Gear Reducers
56C/140TC
115/208-230V AC @ 60 Hz, 95/174-190V AC @ 50 Hz
6.88 in
4.88 in
1
Single
15
60 Series
1
5/8 in
5/8 in
BISSC Certified, Complies with 3A Dairy Standards, Complies with NEMA Definition MG1-1.26.5, CSA Certified, USDA Approved
10 ft-lb
10
Double C-Face Magnetic Disc
95/174 a 190
115/208 a 230
