Home / Capacitor-Start/Run General Purpose Motor, 1/2 HP, 115/208-230V AC Voltage, 56C Frame
Capacitor-Start/Run General Purpose Motor, 1/2 HP, 115/208-230V AC Voltage, 56C Frame
Capacitor-Start/Run General Purpose Motor, 1/2 HP, 115/208-230V AC Voltage, 56C Frame
Capacitor-Start/Run General Purpose Motor, 1/2 HP, 115/208-230V AC Voltage, 56C Frame
Capacitor-Start/Run General Purpose Motor, 1/2 HP, 115/208-230V AC Voltage, 56C Frame
Capacitor-Start/Run General Purpose Motor, 1/2 HP, 115/208-230V AC Voltage, 56C Frame
Capacitor-Start/Run General Purpose Motor, 1/2 HP, 115/208-230V AC Voltage, 56C Frame

Capacitor-Start/Run General Purpose Motor, 1/2 HP, 115/208-230V AC Voltage, 56C Frame

  • Dayton
  • General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1/2 hp HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 4.6/2.4-2.3 A, 56C Frame, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 104 Degrees F, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Dripproof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Face, Motor Mounting Position Horizontal or Vertical Shaft Down, Inverter Rated No

    graingerSKU: 20VD13, mscSKU: , zoro_no: G9078921, mongo_id: 65bbe98022d7a989a995c47e

Web Price
$541.24 / each
Qty

Product Details

Yes
Mexico
Continuous
Continuous
56C
Rolled steel
4.6/2.4-2.3 A
Energy Aware
Product Contributes To Reducing Energy Consumption
1/2
60 Hz
Start Capacitor 540 to 648 MFD, 110V AC, Run Capacitor
B
No
9 3/8 in
1 yr
104 Degrees F
General Application
Ball
Capacitor-Start/Run
Premium Efficient
Open Dripproof
Rolled Steel
Horizontal or Vertical Shaft Down
Face
1.25
Keyed
CW/CCW
Auto
1,725
1
76.2 %
11 7/16 in
1
Single
1701-1800
1,701-1,800
5/8 in
1 7/8 in
UL Recognized for US and Canada (E37403)
115/208-230V AC
115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC
