Home / DC Gearmotor, 710 in-lb Max. Torque, 1.3 RPM Nameplate RPM, 90V DC Voltage
DC Gearmotor, 710 in-lb Max. Torque, 1.3 RPM Nameplate RPM, 90V DC Voltage
DC Gearmotor, 710 in-lb Max. Torque, 1.3 RPM Nameplate RPM, 90V DC Voltage
DC Gearmotor, 710 in-lb Max. Torque, 1.3 RPM Nameplate RPM, 90V DC Voltage
DC Gearmotor, 710 in-lb Max. Torque, 1.3 RPM Nameplate RPM, 90V DC Voltage
DC Gearmotor, 710 in-lb Max. Torque, 1.3 RPM Nameplate RPM, 90V DC Voltage

DC Gearmotor, 710 in-lb Max. Torque, 1.3 RPM Nameplate RPM, 90V DC Voltage

  • Dayton
  • DC Gearmotor, Shaft Orientation Parallel, Motor Enclosure Totally Enclosed Nonventilated, Operating Voltage 90V DC, Motor Type Permanent Magnet DC, Nameplate Speed 1.3 RPM, Maximum Torque 710 in-lb, Overhung Load Capacity 900 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Gear Ratio 1413:1, Input Horsepower 1/20 hp, Output Shaft Diameter 3/4 in, Bearing Type Ball on Motor, Needle Throughout

    graingerSKU: 2H594, mscSKU: , zoro_no: G1130726, mongo_id: 65bbe83a22d7a989a98e248a

Web Price
$959.99 / each
Qty

Product Details

Ball on Motor, Needle Throughout
Ball on Motor, Needle Throughout with Thrust Balls on Case
Externally Replaceable
United States
9.83 in
2.58 in
4.1 in
TENV
0.36 A
0.36 A
Die Cast Aluminum
Hardened Steel
1413:1
Helical, Spur
Totally Enclosed Nonventilated
All Angle
CW/CCW
Parallel
Single
DC Gearmotor
90V DC
Aluminum
1/20 hp
1/20
9.88 in
Permanent Heavy Fluid Gear Oil
40 Degrees C
710 in-lb
40 Degrees C
710 in-lb
Totally Enclosed Nonventilated
Permanent Magnet DC
All Position
Any Angle
1.3 RPM
1.3 RPM
90V DC
3/4 in
1 7/8 in
11.75 in
900 lb
900 ft-lb
1
Yes
Yes
6YHY3
No
CW/CCW
0 to 15
Plastic
Spring Loaded Lip Type on Input and Output Shaft
Spring Loaded Lip Type on Input and Output Shaft
3/4 in
1 7/8 in
Parallel
C-UL Recognized, UL Recognized
Yes
None
90VDC
