DC Gearmotor, RPM 26, 24VDC
DC Gearmotor, RPM 26, 24VDC
DC Gearmotor, RPM 26, 24VDC

DC Gearmotor, RPM 26, 24VDC

  • Dayton
  • DC Gearmotor, Shaft Orientation Right Angle, Motor Enclosure Totally Enclosed Nonventilated, Operating Voltage 24V DC, Motor Type Permanent Magnet DC, Nameplate Speed 26 RPM, Maximum Torque 266 in-lb, Overhung Load Capacity 175 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Gear Ratio 60:1, Input Horsepower 1/8 hp, Output Shaft Diameter 5/8 in, Bearing Type Ball on Motor, Roller on Case

    graingerSKU: 5LAG1, mscSKU: , zoro_no: G1804442, mongo_id: 65bbe96f22d7a989a9954e0c

Web Price
$643.74 / each
Qty

Product Details

Ball on Motor, Roller on Case
Ball On Motor, Roller On Case
Replaceable Externally
United States
TENV
Matt Black
6.3 A
6.3 A
Die Cast Zinc
60:1
Bevel, Spur
Totally Enclosed Nonventilated
All Angle
CW/CCW
Right Angle
Single Right
DC Gearmotor
24V DC
Die Cast Zinc and Steel
Matt Black
1/8 hp
1/8
F
3/16 Sq
3/16 sq in
3/16 sq in
11.75 in
Gear Oil
40 Degrees C
266 in-lb
40 Degrees C
266 in-lb
Totally Enclosed Nonventilated
Permanent Magnet DC
All Position
Any Angle
26 RPM
26 RPM
24V DC
5/8 in
1 1/2 in
175 lb
175 ft-lb
1
No
Yes
33K907
No
CW/CCW
16 to 30
Lip
Lip
Single
5/8
1-1/2
Right Angle
C-UL Recognized, UL Recognized
No
None
24VDC
