Home / MTR, CS/CR, ODP, 1/3 HP, 1725, 56C, EFF 72.4
MTR, CS/CR, ODP, 1/3 HP, 1725, 56C, EFF 72.4
MTR, CS/CR, ODP, 1/3 HP, 1725, 56C, EFF 72.4
MTR, CS/CR, ODP, 1/3 HP, 1725, 56C, EFF 72.4
MTR, CS/CR, ODP, 1/3 HP, 1725, 56C, EFF 72.4
MTR, CS/CR, ODP, 1/3 HP, 1725, 56C, EFF 72.4
MTR, CS/CR, ODP, 1/3 HP, 1725, 56C, EFF 72.4

MTR, CS/CR, ODP, 1/3 HP, 1725, 56C, EFF 72.4

  • Dayton
  • General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1/3 hp HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 3.8/1.9 A, 56C Frame, Hz 60 Hz, Motor Service Factor 1.35, Max. Ambient Temp. 104 Degrees F, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Dripproof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Face, Motor Mounting Position Horizontal, Inverter Rated No, Motor Shaft Design Keyed

    graingerSKU: 30PT39, mscSKU: , zoro_no: G8565164, mongo_id: 65bbe75f3aaddbd5a908f2e5

Web Price
$554.99 / each
Qty

Product Details

Yes
Mexico
Continuous
Continuous
56C
Rolled steel
3.8/1.9 A
Energy Aware
Product Contributes To Reducing Energy Consumption
1/3 hp
60 Hz
Shaft Slinger, Start Cap 238MFD @ 125V
B
No
7 7/8 in
1 yr
104 Degrees F
General Application
Ball
Capacitor-Start/Run
Premium Efficient
Open Dripproof
Rolled Steel
Horizontal
Face
1.35
Keyed
CW/CCW
None
1,725
1
72.4 %
9 15/16 in
1
Single
1701-1800
1,701-1,800
5/8 in
1 7/8 in
CSA (258501), UL (E47479)
115/230V AC
115/200-230V AC, 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 230V AC, 240V AC
