Home / Speed Reducer, C-Face, 56C, 87:1
Speed Reducer, C-Face, 56C, 87:1
Speed Reducer, C-Face, 56C, 87:1
Speed Reducer, C-Face, 56C, 87:1

Speed Reducer, C-Face, 56C, 87:1

  • Dayton
  • Speed Reducer, Input Connection Type C-Face, Gear Type Helical, Spur, Output Shaft Type Keyed, Maximum Output Speed 20 RPM, Motor Frame Designation 56C, Base to Center 4.88 in, Gear Ratio 87:1, Rotation CW/CCW, Maximum Input Horsepower 0.75 hp, Maximum Output Torque 998 in-lb, Overhung Load Capacity 1,192 ft-lb, Mounting Orientation Horizontal, Overall Height 7.47 in, Mount Hole Center-to-Center Length 4.5 in, Application Speed Reducer, Bearing Type Ball, Maximum Input Speed 1,800 RPM

    graingerSKU: 4Z720, mscSKU: , zoro_no: G2727207, mongo_id: 65bbe86b9a749db82278fb25

Web Price
$1,234.99 / each
Qty

Product Details

Speed Reducer
4.88 in
Ball
Ball
5/8
United States
1 in
Standard
Powdered Epoxy Paint
56c
Steel
87:1
Helical, Spur
Die Cast Aluminum
Powdered Epoxy Paint
Hex Head Capscrews, Steel Key, Tube Anti-Seize Compound, Vent Plug
C-Face
1750 rpm
Keyed Shaft
Klubersynth UH1 6-460
0.3 hp
998 in-lb
0.75 hp
1,800 RPM
20 RPM
998 in-lb
56C
4.5 in
5.68 in
Bolt-on
Horizontal
20 RPM
87:1
1
1 in
1 in
4 7/8 in
Keyed
998 in.-lb.
998 in-lb
748 in-lb
3600 in.-lb.
7.47 in
5.69 in
8.44 in
1,192 lb
1,192 ft-lb
1
Hardened Steel
84405
CW/CCW
Double Lip
Parallel Inline
Single Output
Solid
C-Face
AGMA
