Stub Pump, Air Operated, 3/4 In FNPT

Home / Stub Pump, Air Operated, 3/4 In FNPT

Stub Pump, Air Operated, 3/4 In FNPT

SKU
Brand Dayton
Categories Pumps
Description Air Operated Drum Pump, Max. Air Pressure 150 psi, Self-Priming Yes, Discharge Connection Type FNPT, Air Outlet Size 1 3/8 in, Includes Discharge Hose No, Motor Enclosure Motor Housing, Max. Viscosity 440 cps, Includes Suction Tube Yes, Includes Bung Adapter Yes, Includes Nozzle No, Includes Spout No, Adapter Material Aluminum, Zinc
graingerSKU: 33NT22, mscSKU: , zoro_no: G9785106, mongo_id: 65bbe86522d7a989a98f07f7

Web Price

$444.99 / each

Qty

Product Details

Action Type Reciprocating Action

Adapter Material Aluminum, Zinc

Adapter Type Sliding Bung with 2 Drum Thread

Air Inlet Size 1/4 in FNPT

Air Outlet Size 1 3/8 in

Compatible Chemicals Automatic Transmission Fluid, Kerosene, Motor Oil

Country of Origin (subject to change) India

Cylinder Material Aluminum, Steel

DEF Compatible No

Delivers 440 cps

Diesel Exhaust Fluid Compatible No

Discharge Connection Type FNPT

Discharge Size FPT (In.) 3/4

Discharge Tubing Material Steel

For Container Size 5 gal, 15 gal, 30 gal, 55 gal, 275 gal

For Container Type Bucket, Drum, Pail, Tote

For Media Type Automatic Transmission Fluid, Kerosene, Motor Oil

For Use With Low to Medium Viscosity Oils (Up to SAE 80 Oils) for Dispensing Over Distances Up to 5 Meters

Gear Lube NT

GPM 10.00

Grease NT

Height 2-1/2

Housing Material Steel, Aluminum, Brass

Housing Material - Pumps Aluminum, Brass, Steel

Includes Stub Pump with Bung Adaptor, Check Valve, Nipple for Connecting Air Filter

Includes Bung Adapter Yes

Includes Discharge Hose No

Includes Nozzle No

Includes Spout No

Includes Suction Tube Yes

Inlet Size 1

Manufacturers Warranty Length 1 yr.

Max. Air Inlet (PSI) 145

Max. Air Pressure 150 psi

Max. Flow GPM 10 gpm

Max. Flow Rate 10 gpm

Max. Fluid Temp. 122 Degrees F

Max. GPM for Oil 10.60

Max. Head 26 ft.

Max. Head - Pumps 26 ft

Max. Liquid Temp. 122 Degrees F

Max. Oil Flow 10.6 gpm

Max. Outlet Pressure 150 psi

Max. Pressure 145

Max. Viscosity 440 cps

Metered No

Min. Air Pressure 30 psi

Motor Enclosure Motor Housing

Motor Type Air Operated

Not Recommended Chemicals Antifreeze (Coolant), Deionized Water, Diesel Fuel, Ethyl (Ethanol), Fresh Water, Gasoline, Isopropyl (Isopropanol), Lithium Grease, Methyl Ethyl Ketone (MEK), Salt Water, Sodium Hypochlorite/Bleach (to 20%)

Outlet Size 3/4 FNPT

Package Quantity 1

Power Source Air

Ratio 1:1

Seal Material Buna-N, Nylon, Polyurethane

Self-Priming Yes

Type Air Operated, 1:1 Oil Ratio

Wetted Materials Aluminum, Brass, Buna-N, Nylon, Polyurethane, Steel
