Home / Heavy Wall Self Locking Thread Insert, 1/2"-20 Int Thrd Sz, Carbon Steel, 5 PK
Heavy Wall Self Locking Thread Insert, 1/2
Heavy Wall Self Locking Thread Insert, 1/2

Heavy Wall Self Locking Thread Insert, 1/2"-20 Int Thrd Sz, Carbon Steel, 5 PK

  • E-Z Lok
  • Raw Materials
  • Self Locking Thread Insert, Compatible Material Metal, Compatible Tap Size 3/4 In.-10, Drill Bit Size 21/32 in, External Thread Fit 2A, External Thread Size 3/4 In.-10, Finish Black Phosphate, Insert Diameter 3/4 in, Internal Thread Fit 2B, Internal Thread Size 1/2 In.-20, Material Steel, Material Grade/Class 12L14, Maximum Hole Diameter 0.656 in, Minimum Installation Depth 3/4 in, Overall Length 21/32 in, System of Measurement Inch, Thread Direction Right Hand

    graingerSKU: 4ZE26, mscSKU: 96310594, zoro_no: G1007063, mongo_id: 65bbe83a22d7a989a98e356b

Web Price
$13.74 / each
Qty

Product Details

For Use on Metal
163
Yes
United States
21/32 in
2A
3/4-10
Black Phosphate
3/4 in
Screwdriver, Bolt/Nut, or Power Drive Tool
2B
1/2-20
Carbon Steel
3/4
3/4 in
21/32 in
5
4ZE58
3/4-10
78,300 psi
UNC Internal/UNC External
Heavy Wall
