HCL10010, 113 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL10010, 113 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL10010, 113 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

HCL10010, 113 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, High Cycle, Steel, Nominal Capacity 100 ton, Stroke Length 9 7/8 in, Nominal Stroke Length 10 in, Effective Push Area 22.19 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 218.37 cu in, Retracted Height 15.24 in, Extended Height 25.1 in, Outside Dia. 6.89 in, Base Mounting Thread Size M12, Weight 160 lb, Series HCL, Includes (2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve, Bore Dia. 5.31 in

    graingerSKU: 55PP07, mscSKU: , zoro_no: G5521233, mongo_id: 65bbe7519a749db82272f81e

Web Price
$5,454.99 / each
Qty

Product Details

Lift, Push, Hold
M12
Steel
5.31 in
China
100 tons
High Cycle
22.19 sq in
637 mm
(2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve
Steel
10,000 psi
100 ton
10 in
218.37 cu in
218.37 cu in
6.89 in
1
TR 135 x 6
Not eligible for promotion
387 mm
HCL
Single Acting
250 mm
160 lb
