Home / HCL15010, 168 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL15010, 168 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL15010, 168 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL15010, 168 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

HCL15010, 168 ton Capacity, 9.84 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, High Cycle, Steel, Nominal Capacity 150 ton, Stroke Length 9 7/8 in, Nominal Stroke Length 10 in, Effective Push Area 33.14 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 326.21 cu in, Retracted Height 16.1 in, Extended Height 25.9 in, Outside Dia. 8.46 in, Base Mounting Thread Size M12, Weight 255 lb, Series HCL, Includes (2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve, Bore Dia. 6.5 in

    graingerSKU: 55PP13, mscSKU: , zoro_no: G5520743, mongo_id: 65bbe7a79a749db82274c263

Web Price
$8,106.24 / each
Qty

Product Details

Lift, Push, Hold
M12
Steel
6.5 in
China
150 tons
High Cycle
33.14 sq in
659 mm
(2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve
Steel
10,000 psi
150 ton
10 in
326.21 cu in
326.21 cu in
8.46 in
1
TR 165 x 6
Not eligible for promotion
409 mm
HCL
Single Acting
250 mm
255 lb
