Home / RC104, 11.2 ton Capacity, 4.13 in Stroke, General Purpose Hydraulic Cylinder
RC104, 11.2 ton Capacity, 4.13 in Stroke, General Purpose Hydraulic Cylinder

RC104, 11.2 ton Capacity, 4.13 in Stroke, General Purpose Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, General Purpose, Steel, Nominal Capacity 10 ton, Max. Push Capacity 10 ton, Stroke Length 4 1/8 in, Nominal Stroke Length 4 in, Effective Push Area 2.24 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 9.23 cu in, Retracted Height 6.75 in, Extended Height 10.33 in, Outside Dia. 2.25 in, Plunger Dia. 1.5 in, Plunger Thread Size 1 In.-8, Collar Thread Size 2-1/4 In.-14, Base Bolt Circle Dia. 1.56 in, Center Hole Dia. 1 1/2 in, Series RC, Includes Coupler, Dust Cap

    graingerSKU: 6Z783, mscSKU: 80012768, zoro_no: G1098666, mongo_id: 65bbe8e822d7a989a9922e47

Web Price
$821.25 / each
Qty

Product Details

1.56 in
Steel
1.56 in
1 1/2 in
2-1/4-14
China
General Purpose
2.24 sq in
2.24 sq in
10.88 in
Paint
No
Coupler, Dust Cap
10,000 psi
10 ton
10 ton
4 in
9.23 cu. in.
9.23 cu in
2.25 in
1
1.5 in
1-8
Not eligible for promotion
6.75 in
RC
Single-Acting
4 1/8 in
5/16-18
General Purpose
10 tons
