Deep Well Submersible Pump Motor, 1 HP

Home / Deep Well Submersible Pump Motor, 1 HP

Deep Well Submersible Pump Motor, 1 HP

SKU
Brand Flint & Walling
Categories Pumps
Description Deep Well Submersible Pump Motor, Body Dia. 4 in, Diaphragm Type Pressure Equalizing, Hz 60, Full Load Amps 8.2, Height 12 1/8 in, HP 1 hp, Lead Length 48 in, Length Less Shaft 12 1/8 in, Max. Ambient Temp. 86 Degrees F, Max. SF Amps 10.4, Motor Application Pump, Motor Bearings Sleeve, Motor Design Split-Phase, Motor Enclosure Design Totally Enclosed Nonventilated
graingerSKU: 422X53, mscSKU: , zoro_no: G2553551, mongo_id: 65bbe79c3aaddbd5a90a4c90

Web Price

$1,278.00 / each

Qty

Product Details

Body Dia. 4 in

Country of Origin (subject to change) United States

Dia. 3 3/4 in

Diaphragm Type Pressure Equalizing

Full Load Amps 8.2

Height 12 1/8 in

HP_ 1 hp

Hz_ 60

Lead Length 48 in

Length Less Shaft 12 1/8 in

Max. Ambient Temp. 86 Degrees F

Max. SF Amps 10.4

Motor Application Pump

Motor Bearings Sleeve

Motor Design Split-Phase

Motor Enclosure Design Totally Enclosed Nonventilated

Motor Mounting Position Vertical Shaft Up

Motor Service Factor 1.4

Motor Shaft Design Spline

Motor Shaft Rotation CWSE

Motor Sub Application Deep Well Submersible Pump

Motor Thermal Protection Auto

Nameplate RPM 3,450

No. of Speeds 1

Number of Wires 2

Overall Length 13 5/8 in

Overload Relay Max. Amp Setting Not Applicable

Overload Relay Required No

Package Quantity 1

Phase Single

RPM Range 3,001-3,600

Shaft Material Stainless Steel

Shell Material Stainless Steel

Standards CSA (C22.2 No. 100-14), NSF/ANSI 61

Starter Required No

Stator Type Hermetically Sealed

Thrust Rating 700 lb

Usable @ 200V No

Usable @ 208V No

Voltage 230V AC

Voltage Compatibility 115/200-230V AC, 115/208-230V AC, 115/230V AC, 120/240V AC, 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/277V AC, 208-230/460V AC, 230V AC, 240V AC, 277/230V AC
