Electric Actuator, 35 in.-lb.-4 to 125F

SKU
Brand Johnson Controls
Categories Electric and Cordless Tools
Description Actuator, Valve Application Damper, Signal Type Proportional, Rated Torque 35 in-lb, Input Voltage 24V AC, Electrical Connection Type Screw Terminals, For Use With Building Automation Systems Building Automation System Compatible, NEMA Rating 1, IP Rating IP40, Spring Return Non-Spring Return, Time to Close 30 sec, Shaft Type Self-Centering Clamping, Shaft Rotation CW/CCW, Stroke Degree 93 Degrees , Mounting Type Direct Mount, Maximum Operating Temperature 140 Degrees F

Web Price

$242.49 / each

Product Details

Ambient Temp. Range -4 Degrees to 125 Degrees F

Country of Origin (subject to change) Mexico

Depth 2 1/4 in

Electrical Connection Type Screw Terminals

Electrical Connections Screw Terminals

For Shaft Diameter 1/2 in

For Shaft Height 3/8 in

For Shaft Shape Round, Square

For Shaft Width 3/8 in

For Use With Dampers and Valves

For Use With Building Automation Systems Building Automation System Compatible

Height 5 5/32 in

Includes Anti-Rotation Bracket

Input Voltage 24V AC

IP Rating IP40

Maximum Operating Temperature 140 Degrees F

Minimum Operating Temperature -4 Degrees F

Motor Direction CW or CCW

Mounting Type Direct Mount

NEMA Rating 1

Number of Auxiliary Switches 0

Overall Depth 2 1/4 in

Overall Height 5 1/8 in

Overall Width 2 7/8 in

Package Quantity 1

Power Consumption 3.6 VA

Product Type Actuator

Rated Torque 35 in-lb

Shaft Rotation CW/CCW

Shaft Type Self-Centering Clamping

Signal Type Proportional

Spring Return Non-Spring Return

Standards C-Tick Mark Australia, CE Certified, CSA Certified C22.2 No. 139, EMC Directive 2004/108/EC, Guide No. XAPX for USA and Canada, NZ Emissions Compliant, UL Listed 60730-1, UL Listed E4436

Stroke Deg. 90

Stroke Degree 93 Degrees

Time to Close 30 sec

Timing 60 sec

Torque 35 in-lb

Valve Application Damper

Voltage 24V AC

Width 2 13/16 in
