Female Stud, SS/PTFE Race Rod End, LH, 38mm
Female Stud, SS/PTFE Race Rod End, LH, 38mm

Female Stud, SS/PTFE Race Rod End, LH, 38mm

  • Qa1
  • Raw Materials
  • Spherical Rod End, System of Measurement Metric, Ball Stud Center Length 74 mm, Ball Stud Thread Length 34 mm, Ball Stud Thread Size M16-2.0, Bore Diameter 16 mm, Head Outside Diameter 38 mm, Head Width 12.75 mm, Shank Thread Length 33 mm, Shank Thread Size M16-2.0, Housing Material Stainless Steel, Shank Thread Direction Left Hand, Application Light Duty, Ball Diameter 28.58 mm, Ball Material Stainless Steel, Ball Material Grade 440C, Ball Stud Material Stainless Steel

    graingerSKU: 39N521, mscSKU: , zoro_no: G5743193, mongo_id: 65bbe83422d7a989a98e146e

Web Price
$104.36 / each
Qty

Product Details

Light Duty
440C Stainless Steel Spherical
28.58 mm
Stainless Steel
440C
74 mm
Stainless Steel
Left Hand
34 mm
M16-2.0
440C SS Spherical Ball
16 mm
+0.065/-0.012 in
Follows SAE Specification J1120
China
M16 x 2.0
24 mm
38 mm
38 mm
64 mm
33 mm
83 mm
21 mm
38 mm
12.75 mm
300 Series Stainless Steel
Stainless Steel
Chrome Plated
21 mm
33 Degrees
33 Degrees
83 mm
1
PTFE
Corrosion Resistant
Spherical Rod End
Yes
Left Hand
Female
33 mm
M16-2.0
Female Studded
ISO Certified 9001
25,162 N
25,162 N
38 mm
Metric
Left Hand
M16 x 2.0
Female Studded
